7 Feet V-Belt Drive Heavy Duty Lathe Machine

2,70,000 / 25 pieces

Product Specification:

Bed Length	7 Feet
Height of Centre	254 mm
Swing Over Bed	455 mm

Product Description:

Heavy Duty Lathe Machines are one of the most extensively utilised lathe machines because of its...

View Complete Details

Product Details
Company Details

Product Specification:

Bed Length	7 Feet
Height of Centre	254 mm
Swing Over Bed	455 mm
Spindle Bore	52 mm
Machine Type	Belt Driven Heavy Duty Lathe Machine
Applicable Industry	Mining, Steel Rolling Mills, Power Plant, Oil Industry, Shipbuilding
Bed Width	325 mm
Number of Spindle Speeds	8
Distance Between Centre	965 mm
Swing Over Cross Slide	285 mm
Maximum Swing in Gap	775 mm
Cross Slide Travel	280 mm
Spindle Speed Range	25-500 RPM
Lead Screw Diameter	38 mm
Lead Screw Pitch	4 T.P.I
Tail Stock Spindle Diameter	52 mm
Tail Stock Spindle Taper Bore	MT-4
Tail Stock Spindle Travel	190 mm
Motor Power	2 HP
Range of Metric Thread	1-6 mm
Range of Inch Thread	4-24 T.P.I

Product Description:

Heavy Duty Lathe Machines are one of the most extensively utilised lathe machines because of its high quality and rapid rate of output. These are made of high-quality iron and steel and are built to withstand the most difficult shaping chores. They are particularly well suited to high-volume production because to their high-performance capacity to work at fast speeds..

We offers wide range of lathe machines in various sizes, specifications and features depending on the Customer requirement.

Company Description :

Since our establishment in 1968, we have been dedicated to keeping pace with technology to meet the needs of quality hydraulic jack products, today ?MASKO? is recognized in hydraulic jacks for tractor-trailers and bulldozers attached to tractors. Known as a symbol of quality. In agricultural sector while in industrial needs like hydraulic cylinders for cement mixers and other custom made hydraulic cylinders. We have decided to carve a niche for ourselves in the highly competitive field of designing, manufacturing and marketing all types of Manual Drum Lifting Jacks, Hydraulic Power Tanks and Manual Pumps and Hydraulic Tensioners. At ?MASKO? quality is always given top priority, our products are characterized by excellent reliability, durability and high level of performance. Above all, "Moscow" is a team of professionals, dedicated to providing services to the vital needs of clients. Under the supervision of Mr. Askokbhai Somaiya, one of the directors of the company, every product, part and material of ?Moscow? has gone through strict quality checks and is thoroughly verified and inspected at every process. These quality controls are done as per SQC system. And all products are 100% tested for performance as per the recommendations of Indian Standards. Our mentor ?Mr. Monish Somaiya? has a deep understanding of market processes and functioning. With his constant encouragement and rich business acumen, we have outperformed our counterparts in the market.
